Αριθμός ανταλλακτικού 629-501

Hydraulic Ram
Διαθεσιμότητα αποθεμάτων  Κωδικοί κατάστασης προϊόντος

Αριθμός ανταλλακτικού 629-501 είναι σε απόθεμα στις ακόλουθες ποσότητες και συνθήκες.

  • NS: 2
  • AR: 1
  • NE: 1

Σημείωση: Η διαθεσιμότητα αυτού του στοιχείου ενημερώθηκε τελευταία φορά 11/23/2022 και μπορεί να έχουν αλλάξει από τότε. Ζητήστε προσφορά για ενημερωμένες τιμές και διαθεσιμότητα.

Τιμολόγηση και διαθεσιμότητα

Υποβάλετε αυτήν τη φόρμα για τις τρέχουσες τιμές και τη διαθεσιμότητα αυτού του NSN.
Αριθμός ανταλλακτικού:
Ποσότητα:
Διεύθυνση ηλεκτρονικού ταχυδρομείου:
Τηλέφωνο:
Αναφορά:
Εταιρεία:
Όνομα:

Δεν μοιραζόμαστε ούτε πουλάμε τις πληροφορίες σας σε κανέναν.
Μυστικότητα | Όροι

All major credit cards accepted as well as gov. p-cards

Η ιστορική τιμολόγηση για αυτό το προϊόν είναι μεταξύ 1324.34 and 1787.859 USD. Ανάλογα με την ποσότητα, τη διαθεσιμότητα, την κατάσταση, τον χρόνο παράδοσης και την πιθανή διακοπή ενός προϊόντος, δεν μπορούμε να εγγυηθούμε την τιμολόγηση μέχρι να σας παρέχουμε μια ενημερωμένη προσφορά.

Αριθμός ανταλλακτικού
Αποστρατιωτικοποίηση
Διάρκεια ζωής
UOM
NIIN
Αριθμός ανταλλακτικού:
629-501
Αποστρατιωτικοποίηση:
No
Διάρκεια ζωής:
N/A
Μονάδα μέτρησης:
1 EA
NIIN:
000851867
NSN
Εθνικός αριθμός αποθέματος:
4320-00-085-1867 4320000851867
TXT
Περιγραφή:
Hydraulic Ram
INC
INC
Κωδικός ονόματος στοιχείου:
13126
MRC:
A measurement of the longest straight line across a circular cross-sectional plane.ADAV
Overall Diameter:
3.875 inches
MRC:
A measurement from the bottom to the top of an object,in distinction from depth.AJLT
Extended Height:
8.312 inches
MRC:
The length of a straight line which passes through the center of a coaxial cylinder which would bound the crest of an external thread or the root of an internal thread.AJYN
Screw Thread Diameter:
0.375 inches
MRC:
A designation distinguishing one group of screw thread diameter-pitch combinations from another by the number of threads per measurement scale for a specific diameter.AJYP
Screw Thread Series Designator:
Ips
MRC:
The number of screw threads on the item per linear inch measured on a line parallel to the thread axis,including incomplete threads.AJYQ
Screw Thready Qty Per Inch (tpi):
18.000
MRC:
A measurement from the mounting base to the top of an item,when retracted,in distinction from depth.ALPK
Retracted Height:
6.312 inches
MRC:
A measurement of the capacity of an item.AXQD
Capacity:
20.0 tons
MRC:
The length of a straight line which passes through the center of a plunger,and terminates at the circumference.AXQF
Plunger Diameter:
2.000 inches
MRC:
An indication of whether or not a carrying handle is included.AXQG
Carrying Handle:
Not included
